Revit × Rhino Interoperability: 5 Smart Workflows to Save Time and Headaches

Here are the five most common workflows we’ve seen across industry-leading architecture firms, plus protocol tips to make your life easier.

1 Start in Revit, Add Design Detail in Rhino

Use Revit to lay the groundwork, then use Rhino to enrich the design.

Start with the basics in Revit, grids, levels, and massing, then switch to Rhino for flexible form-finding or advanced geometry. Finally switch back and forth to make sure the overall geometry is updated.

Revit sets the design framework (e.g., curtain wall grids), while Rhino.Inside.Revit enables you to populate that framework with complex or variable forms using RhinoCommon and/or Grasshopper. This approach allows controlled, rule-based design exploration while maintaining a strong Revit foundation.

2 Automate Geometry Transfer with Native Elements

Make sure what goes into Revit works like it belongs there.

Transferring geometry from Rhino to Revit can be easy, but making sure it behaves like real Revit elements is what really matters.

Instead of importing geometry as static shapes (DirectShape), use custom Grasshopper scripts on top of other tools like BEAM,to recreate geometry as native Revit elements rather than direct shape. This improves model performance, allows for tagging, scheduling, and simplifies downstream coordination. Use modular scripts and keep a shared library of fixes for recurring issues.

3 Use Rhino for Context Modeling

Build the surrounding environment in Rhino, and bring it into Revit cleanly.

Rhino is great for quickly modeling complex site context, like topography or surrounding buildings.

Use Rhino for freeform modeling of urban or landscape surroundings, then bring models into Revit using Rhino.Inside. To avoid bloated Revit files, simplify geometry and chunk it into manageable pieces. Establish layer naming and LOD standards early (e.g., L-VEG-TREE for low-detail vegetation). Clean geometry before importing.

4 Visualize in Rhino, Review and Document in Revit

Make it look great in Rhino, but present it clearly in Revit.

Rhino and Grasshopper can create beautiful visuals, but make sure final design reviews and sheets live in Revit.

Define standard export formats from Rhino (e.g., PNGs with transparent backgrounds or DWGs for 2D linework) and align these with shared coordinates for consistency in Revit sheets. Keep visual output simple and structured so consultants and clients reviewing in Revit files don’t miss key design intent.

5 Create a Shared Interoperability Protocol

Agree on the rules up front to avoid pain later.

Set clear ground rules for how files, models, and scripts are structured across both platforms.

Add these to your BIM Execution Plan or team handbook:

Model Origin & Units: Align coordinate systems early.

Geometry Cleanliness: Limit model resolution before transfer to avoid performance issues.

Layer → Category Mapping: Map Rhino layers to Revit categories (e.g., site elements, trees, roads).

Naming Conventions: Use consistent naming across scripts and families (e.g., _RVT, _GH).

Performance Flags: Set size or complexity limits for imported geometry, especially when using DirectShapes.

‍
